H-beam, also known as wide flange beam or I-beam, is a structural steel beam with an "H" shape cross-section. H-beams are widely used in construction and structural engineering due to their strength, versatility, and cost-effectiveness. They are characterized by their distinctive shape, which resembles the letter "H" when viewed in cross-section.Key features of H-beams include:
Wide Flanges: H-beams have wide flanges at the top and bottom of the beam, which provide increased strength and support compared to other beam shapes. The wide flanges distribute the load evenly across the beam's cross-section, making them suitable for supporting heavy loads and resisting bending and deflection.
Parallel Flanges: The flanges of H-beams are parallel to each other and perpendicular to the web, which helps distribute the load evenly and provides stability and structural integrity.
Thick Web: H-beams have a thick vertical web connecting the flanges, which provides additional strength and support to the beam. The web helps resist shear forces and prevents the beam from buckling under load.
Versatility: H-beams are available in various sizes, lengths, and grades to suit different construction and structural engineering applications. They can be easily fabricated, cut, drilled, and welded to fit specific project requirements.
Shandong Yuanda Metal Products Co., Ltd. continuously meets customers’ requirement.We also supply customized service. Shandong Yuanda Metal Products Co., Ltd. strives to build long-term relationship with all of partners and provide products with prime quality and competitive price.More details, feel free to contact us.
| Standard | ASTM, ASME, EN, BS, GB, DIN, JIS, etc |
| Surface Treatment | Two lays of Anti-rust Painting,Hot Dip Galvanized,Black |
| Material | G350 S275JR S355JR,SS400,ASTM36,S235jr,S235jo, Q235B and Q345B ，SS304 ,SS316,etc |
| size | 1.Web Width (H): 100-900mm
2.Flange Width (B): 100-300mm
3. Web Thickness (t1): 5-30mm
4. Flange Thickness (t2): 5-30mm Or Customers' requirements |
Advantages | 1. Lower cost with better quality. 2. High safety performance. 3. Easy to assemble and dismantle. 4. Manufacture under complete
quality control system - ISO9001. 5. Installation with instruction of experienced engineers 6. Non-pollution. |
Application | It is widely used in beam and column components of industrial and civil construction steel structure. Steel structure load-bearing support for industrial structures. Ship and machinery manufacturing frame structure. Steel piles and supporting structures of underground engineering, etc. |
Packing&Shipping:
packing | 1.By steel strips in bundles |
| 2.By woven cloth with 7 slats |
| 3.By woodenn pallet |
| 4.Accorging to the requirements of customers |
Delivery | By sea | 1.In bulk ( based on 200tons) |
| 2.20ft container: 25tons (Length limted 5.8m MAX) |
| 3.40ft container: 25tons (Length limted 12m MAX) |
| By air | UPS/DHL/FEDEX |
| By truck | as customer ruquests |
European Standard Size:
| Type | Width of section(mm) | Depth of section(mm) | Web(mm) | Flange(mm) | Mass per metre(Kg/m) |
| HEA120 | 120 | 114 | 5 | 8 | 20.4 |
| HEA140 | 140 | 133 | 5.5 | 8.5 | 25.3 |
| HEA160 | 160 | 152 | 6 | 9 | 31.2 |
| HEA180 | 180 | 171 | 6 | 9.5 | 36.4 |
| HEA200 | 200 | 190 | 6.5 | 10 | 43.4 |
| HEA220 | 220 | 210 | 7 | 11 | 51.8 |
| HEA240 | 240 | 224 | 6.5 | 9 | 48.6 |
| HEA260 | 260 | 250 | 7.5 | 12.5 | 69.5 |
| HEA280 | 280 | 270 | 8 | 13 | 78.3 |
| HEA360 | 300 | 350 | 10 | 17.5 | 112 |
| HEA300 | 300 | 290 | 8.5 | 14 | 90.5 |
| HEA400 | 300 | 390 | 11 | 19 | 125 |
| HEA450 | 300 | 440 | 11.5 | 21 | 140 |
| HEB140 | 140 | 140 | 7 | 12 | 34.5 |
| HEB160 | 160 | 160 | 8 | 13 | 43.7 |
| HEB200 | 200 | 200 | 9 | 15 | 62.8 |
| HEB300 | 300 | 300 | 11 | 19 | 119.9 |
| HEB360 | 360 | 360 | 12.5 | 22.5 | 142 |
| HEM300 | 310 | 340 | 21 | 39 | 244 |
| HEM320 | 309 | 359 | 21 | 40 | 251.1 |
| HEM400 | 307 | 432 | 21 | 40 | 256 |
| HEM450 | 307 | 478 | 12 | 40 | 263 |
Other Steel Products:
| Steel H Beam, I Beam |
| Steel channel |
| Steel angle bar, round bar |
| Steel flat bar, steel plate |
Check below for more information on placing an order:
1. Inquiry-Professional quotation. |
2. Confirm the price,size,grade,length, lead time, technique, payment term etc. |
3. our sales send the Proforma Invoice with our seal |
4. Customer make the payment for deposit and send us Bank receipt. |
5. Initial Production Stage-Inform the clients that we have got the payment,And will make arrange the production |
6. Middle Production-send photos to show the production line which you can see your products in.Confirm the e |
7. End Production-Mass production or stocks,products photos will send to you for approval. You can also arran |
8. Clients make payment for deposit and Ship the goods , Inform the tracking number and check the status for clie |
9. Order can be say "finish" when you receive the goods and satisfy with them, pay the balance too. |
10. Feedback to our about Quality , Service, Market Feedback & Suggestion. And we can do better |
